ESP32 WiFi Bluetooth Dual Mode IoT Dev Board

This is the NodeMCU development board based on ESP32, features WiFi+Bluetooth connectivity, onboard CP2102 and keys. What's more, all the I/O pins of ESP32 module are accessible via the extension headers. See the new NodeMCU ESP32U version as well. Thanks to the rich open-source resources, it supports development in various ways such as Lua/AT commands/MicroPython/Arduino/IOT source code, etc. helps you to fast prototype IoT applications. Features : Onboard ESP32 module Onboard CP2102, USB to UART converter USB port for power input, firmware programming, or UART debugging 2x15pin extension headers, breakout all the I/O pins of the module 2xkeys, used as reset or user-defined Specifications : WIFI module: ESP32 Processor: ESP32 Built-in Flash: 32Mbit Antenna: Onboard PCB antenna Peripheral interface: UART/GPIO/ADC/DAC/SDIO/PWM/I2C/I2S WiFi protocol: IEEE 802.11 b/g/n Bluetooth: Bluetooth 4.2 Frequency range: 2.4G ~ 2.5G (2400M ~ 2483.5M) WIFI mode: Station / SoftAP / SoftAP+Station Power supply: 5V Logic level: 3.3V Dimensions: 51.4mm x 25.4mm Applications : The NodeMCU-32 suit for IOT applications such as: Smart home Intelligent building Industrial automation Wearable devices IP camera Intelligent agriculture
